Panels

Panels are the readouts on your desktop. They sit under your windows, on the left side of your primary monitor until you move them, and show live readings: how busy your machine is, your network, your disks, your projects and your notes. Every reading is real. Hover over any part of a panel to see what it is.

bromigOS’s own files sometimes call panels widgets. Settings › Widgets is where you choose them.

Show and hide panels

The panels

The panels marked “no” are off until you add them: open edit mode, find one in the tray, and click Add to desktop. Each one says on the panel itself what it needs before it can show anything, such as a calendar’s address or a sign-in.

Use the panels

• WORKBENCH. Each project has buttons to open it in the editor, in a terminal, or in the file manager.
• SHORTCUTS. Click a row to run that key’s action. Keys that move windows or workspaces only work from the keyboard.
• CONNECTIONS. Click a Wi-Fi network to join it.

Storage names

To give a drive a shorter name, open Settings › Widgets, find STORAGE, and open its Settings…. In Drive display names, enter one mount path and name per line, such as /mnt/Work = Work. Clear an entry to show its mount path again.

Names appear at every widget size. Hover still shows the full mount path, and clicking opens that folder. This changes the widget’s text only; it does not rename the drive.

From a terminal, set the whole list with:

bromigos panels set storage display_names '/ = System' '/mnt/Work = Work'

Field notes

FIELD NOTES is a notepad on your desktop. It saves as you type.

1. Press Alt+N. The panel is ready for typing.
2. Type your note.
3. Press Esc to go back to your windows.

To add one line without leaving what you’re doing, press Alt+Shift+N, type it, and press Enter. It’s added to your notes with the time.

Your notes are a plain text file, ~/.local/share/bromigos/notes.md.

Arrange the panels

Edit mode lets you move, resize and choose panels right on your desktop.

1. Press Super+Alt+W, or right-click any panel. You can also choose Edit widgets in the menu (Super+Space).

2. The panels come up above your windows, each with a frame. A tray with every panel opens on the right.



3. Drag a panel to move it. It snaps into line with the others. Hold Ctrl to place it freely. To put it on another monitor, drag it over that monitor’s edge.

4. Drag a corner to make it bigger or smaller.

5. Click a panel’s × to hide it. To bring one back, flip its switch in the tray, or click Add to desktop to put it in a free spot.

6. Press Esc or click Done to save. Cancel puts everything back.

Bigger panels show more, not just the same thing larger. A large SYSTEM panel adds the busiest programs and every temperature, and a wide WEATHER panel shows the hours ahead. Each panel’s card in the tray has buttons for its sizes, such as Compact and Large.

Ctrl+Z undoes a change. Reset… in the tray puts every panel back where bromigOS first had it.

More than one monitor

Each panel can go on any monitor. Drag it across, or pick it and choose a monitor in the tray’s Monitor list. A panel knows its monitor even when you plug it into another port. When you unplug a monitor, its panels move to your primary monitor for the time being. They go back to their places when you plug it in again.

The same goes for switching your monitor off and on, even when it’s your only one. Each panel goes back exactly where it was, so you don’t need to apply your layout again.

You can do it all from the keyboard. Tab picks the next panel, the arrow keys move it (with Shift, 10 pixels at a time), Ctrl and an arrow resizes it, and H hides it. F6 moves to the tray and back.

Why not just hold Alt and drag? On bromigOS, Alt and a drag moves windows, so it can’t move panels too.

Layouts

A layout is a ready-made set of panels, already sized and placed for you. Pick one and your desktop changes at once. Each panel keeps its own settings, such as the weather’s place.

To pick one:

1. Open Customize (Super+Ctrl+Shift+Space) and choose the Widgets tab. The Layouts row is at the top.
2. Each card is your screen in miniature, with your theme’s scene behind it. It shows where each panel would go. The dashed boxes are the parts of the scene a layout keeps clear.
3. Click a card, or its Use this layout button.
4. Changed your mind? Click Undo.

In edit mode, the tray’s Layouts… button lists them too. There, Ctrl+Z undoes one, and Done keeps it. In a terminal, bromigos panels layouts lists them, and bromigos panels layout apply homelab applies one.

Layouts fit any screen, from a 1366×768 laptop to a 4K or ultrawide monitor. On a small screen, panels come in smaller sizes. A layout never covers more than about a third of the screen, so you can still see your scene. When a panel doesn’t fit, or can’t show anything on your machine, the layout leaves it out and says why. For example, GITHUB needs you to be signed in, and LAB needs a homelab. Everything is the exception: it may cover more, and it tells you when it does.

Each theme has its own layout

Your scene is the point of your desktop, so each theme keeps the panels off its best parts. The Wick keeps its screens, TVs and window clear. Tidewell keeps the waterline, the lighthouse and the creatures’ water clear. Mire keeps the Sleeper and Hollis clear.

Your desktop remembers a layout for each theme. When you switch theme, your panels switch to the layout you last had on that theme. The first time, you get the layout made for it. The colour themes (Cinder, Deepvein, Highwind, Lowtown, Rime, Sunder, Wick · Tidewell and Wick · Mire) paint the Wick’s den in other colours, so they share the Wick’s layout. Switching between them leaves your panels alone.

To use one layout on every theme, run bromigos panels layout apply minimal --all-themes.

Save your own

Arrange the panels the way you like, then choose Save as layout… in the edit-mode tray. Or open Customize › Widgets and click New layout… beside Layouts. Enter a name and, optionally, a description, then save. The form captures the current arrangement on the screen it names. Your new layout joins the cards marked yours.

To update a saved layout, choose Save changes… on its card. The form names the layout that will be replaced with your current arrangement. Override… does the same for a ready-made preset, saving your own version. Packaged preset files stay available on disk. The theme’s own card offers Save as new….

Saving does not apply the selected card first. Use Use this layout, arrange the widgets, and then save changes if you want to start from that card. A new name that matches an existing layout is rejected; use its save or override action instead. These actions are also available from Settings › Widgets › Layouts.

From the terminal:

bromigos panels layout save "My desk"
bromigos panels layout save --replace my-desk
bromigos panels layout apply my-desk

The first command creates a layout, the second updates it, and the third puts it on your desktop. Add --monitor <name> to choose a screen when saving.

Tidy up

Panels on top of each other? Click Tidy up in edit mode’s tray, in Customize’s Layouts row, or in Settings › Widgets. You can also run bromigos panels tidy. Tidy up moves your panels so none covers another. It keeps them in the same order, and keeps them off the scene where it can. Undo puts them back.

When you switch on a panel and there’s no room left for it, bromigOS tells you: “No room for GPU: hide something or try a smaller size”. It never puts one panel on top of another.

Panels that fit what they show

Some panels show lists that grow and shrink, such as LAB, ALERTS and CI & PRs. These panels take the height their content needs. A layout gives LAB room for your whole lab, and ALERTS with four alerts is a short panel, not a big empty box. As the list changes, the panel’s frame follows it, inside the room it was given. It changes only now and then, so it doesn’t jump around.

When a panel has less room than its content needs, it shows less instead of cutting anything off. LAB, for example, shows “34/36 UP” and only the services that are down. Make it taller to see everything again.

Making a panel bigger

When you make a panel bigger, it stays where it is. Panels in its way move down or to the side. If they can’t, the panel moves to free space, never onto the scene’s screens or window. If there’s no room anywhere, nothing changes and bromigOS tells you: “No room to make LAB 900 tall here: move or hide something”.

Choose panels

The tray in edit mode, the Widgets tab of Customize and Settings › Widgets all show the widget gallery: every panel there is, on or off. Each one says what it shows, who made it and what it reads. Type in the search box, or pick a category, to find one.

Get more widgets, in Settings › Widgets, lists widgets other people made, from the bromigOS catalog. Each shows who made it, its licence and a link to its code. A widget is a small program, so Install… opens a terminal that tells you what it can do and asks before it installs. Uninstall removes it again.

To install a widget someone shared as a link, click Install from URL… in Settings › Widgets and paste the link. Settings shows what the widget reads and what it can do before anything is installed, and installs it only when you click Install.

Settings › Widgets also shows a small picture of where the panels sit. Its Monitor for every panel puts them all on one monitor.

You can also choose and place panels from a terminal:

bromigos panels                   # which panels are on, and where
bromigos panels edit              # start edit mode on the desktop
bromigos panels show weather      # turn one on
bromigos panels add weather       # turn one on, in a free spot
bromigos panels hide connections  # turn one off
bromigos panels move notes 514 16 # move one, in pixels from the top-left
bromigos panels size notes 470 400 # resize one: width and height in pixels

Media

MEDIA is a remote for the den TV: all three screens at once, what each is showing and where the sound comes from. Click a screen’s line to choose it, then use the buttons to change its channel, turn its sound on or off, watch it full screen, or open the channel guide. It comes in three sizes:

• compact: a line for each screen, and the buttons;
• wide: each screen with its poster and what’s next;
• large: what you were part-way through on your server, and what’s new, with posters.

Click something you were watching to open it in Jellyfin or Plex, which remember where you were.

Its Settings… make a TV channel without editing a file. Choose a source and a library, collection or playlist from your server, or paste a YouTube address. You can also choose the den screen, the order, and a folder to keep YouTube videos in. For every other channel, the form links to the channel guide.

Set up the weather

The WEATHER panel fetches nothing until you say where you are.

1. Open Settings › Widgets.
2. Under Weather, type your town in Place, and choose the Units.
3. Under Panels, turn the weather panel on.

Or from a terminal:

bromigos panels weather place "San Diego"
bromigos panels weather units imperial
bromigos panels show weather

The forecast comes from Open-Meteo, a free weather service.

Calendar releases

CALENDAR can add tracked TV episodes and film releases to your calendar. Open its Settings… and turn on Your media server’s releases. Sonarr or Radarr must be connected in Your homelab.

The setting is media = true in ~/.config/bromigos/widgets/calendars.toml. It adds releases without replacing your other calendars. For the whole workflow, see Your media.

To export the releases as calendar files for another app:

bromigos lab media calendar tv > ~/Downloads/tv-releases.ics
bromigos lab media calendar movies > ~/Downloads/film-releases.ics

These are copies of the feed at that moment. Export again to update them. --past and --future set how many days to include. The panel reads fresh releases by itself.

A panel’s own settings

Many panels have settings of their own, such as which calendars to show or which Discord server to watch. Click Settings… on the panel’s card, in edit mode’s tray or in Settings › Widgets. The panel changes as soon as you save.

From a terminal:

bromigos panels settings calendars            # what it has, and the values now
bromigos panels set discord invite abc123     # change one

Panels that need an account

GITHUB, GITLAB, SPOTIFY and TWITCH show your own account, so they need you to sign in once. Open the panel’s Settings… and click Sign in.

1. Connect the service, if asked. GitHub, gitlab.com and Twitch need nothing: bromigOS has its own apps for them. Spotify, and a GitLab or GitHub server of your own, need an app of your own. The form says where to make it and what to paste. You do this once per service, and every panel for that service shares it.
2. Sign in. For GitHub, GitLab and Twitch, a short code appears. Type it on the page that opens, and approve. For Spotify, approve on Spotify’s page; the form finishes by itself.

The sign-in is kept in your login keyring, never in a file. Sign out forgets it.

If you use the gh command and you’re signed in to it, GITHUB uses that, and there’s nothing to do. GITLAB can also take a personal access token: Paste a token….

Several accounts

You can sign in to more than one account of a service. For example, gitlab.com and your company’s own GitLab, GitHub and a GitHub Enterprise server, or two Twitch accounts. One panel shows them all.

1. In the panel’s Settings…, click Add another account….
2. Give it a short name, such as work. For GitLab and GitHub, give its server’s address too, or leave it empty for the public site.
3. A server of your own needs its own app, so the form asks for its client ID. Then click Sign in, as for the first account.

With two accounts signed in, the panel merges their rows, newest first. Each row shows which account it came from, such as gitlab.com or work. Each account has a tick box in the form: untick it to leave that account out of this panel. Remove… signs an account out and forgets it, after asking. SPOTIFY shows one account at a time: the first one ticked.

From a terminal:

bromigos account login twitch
bromigos account status twitch
bromigos account logout twitch
bromigos account configure spotify client_id=YOUR_CLIENT_ID      # services without a bromigOS app

bromigos account add gitlab work base=https://git.example.org    # another account, on its own server
bromigos account configure gitlab --as work client_id=YOUR_APP_ID
bromigos account login gitlab --as work
bromigos account list                                            # every account, and who's signed in
bromigos account remove gitlab work

The developer docs’ widgets.md say, for each panel, where to make the app.

Panels of your own

• For your homelab: a gauge, a chart, a status light or a table needs no code. You describe it in a settings file. See Your own panels.
• With code: a panel can be a small Python file in ~/.config/bromigos/plugins/widgets/, or an extension. Make your own widget walks you through it. The developer docs’ plugins.md shows how.

Where the settings go

Your layout is ~/.config/bromigos/widgets/layout.json, and the weather’s place is in ~/.config/bromigos/weather.toml. A panel’s own settings are in ~/.config/bromigos/widgets/<name>.toml, and the services’ client IDs in ~/.config/bromigos/accounts.toml. Settings writes them all for you. If you edit them by hand, run bromigos widgets reload.
